Water Cooled Screw Chiller

Name: Water Cooled Screw Chiller
Brand: AQUATECH PLUS PVT. LTD.
Price: 150000.0 INR
Availability: InStock

Price 150000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Water Cooled Screw Chiller Specification

Water Flowing Rate
300

Air Flow
15000 ft3/min (CFM)

Application
chilling water

Material
Metal

Refrigerating Capacity
4 tr

Motor
High-efficiency VFD controlled motor

Usage
Industrial

Condition
New

Type
air cooled

Size
Standard

Dimension (L*W*H)
1140 560 1040 Millimeter (mm)

Height
540 Millimeter (mm)

Product Type
Water Cooled Screw Chiller

Power Supply
400V-50Hz

Weight
50 Kilograms (kg)

Voltage
440 Volt (v)

Color
White And Green

Cooling Type
water cooled

Length
1140 Millimeter (mm)

Width
1040 Millimeter (mm)

Nozzle Material
metel

Cooling Coil Material
copper

Water Pump Motor
0.5 hp

Noise Control
30 db

Compressor
Semi-hermetic screw type (energy-efficient with VFD control)

Warranty
1 Year

Water Cooled Screw Chiller Trade Information

Minimum Order Quantity
1 Unit

FOB Port
MUNDRA

Payment Terms
Letter of Credit (L/C), Cash on Delivery (COD), Cheque, Telegraphic Transfer (T/T)

Supply Ability
5 Units Per Month

Delivery Time
15 Days

Sample Available
No

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
standard packaging

Main Export Market(s)
Africa, Asia, Australia, Middle East

Main Domestic Market
All India

Certifications
ISO/IEC 17025:2017 , CE, ROHS,ISO 9001:2015 IEC

About Water Cooled Screw Chiller

Industrial & Manufacturing Applications:

Plastics Processing : Injection molding, blow molding, extrusion
Thermoform Machines Temperature control for plastic sheet forming
Coating Systems : Regulating temperature for uniform coatings
Surface Processing : Electroplating, anodizing, and metal finishing
Welding Engineering : Cooling for welding torches and laser welding
Machine Tools : Spindle cooling, cutting fluid cooling

Energy & Environmental Applications:

Biogas & Natural Gas Treatment : Cooling for gas purification systems
Compressed Air Treatment : Removing moisture in air compression systems
HVAC & Building Cooling : Climate control for commercial buildings

Medical & Pharmaceutical Applications

Chemical & Pharmaceutical Processes : Temperature-sensitive reactions
Medical Imaging Systems : MRI, CT scan cooling
Laser Technology : Cooling for medical and industrial laser systems

Printing & Packaging Applications:

Flexographic Printing Systems : Ink cooling for high-speed printing
Offset Printing Machines: Maintaining ink viscosity and press stability

Advanced Technology & Electronics

Semiconductor & PCB Manufacturing: Cooling electronic components
Data Centers & Server Cooling : Preventing overheating of IT infrastructure

Food & Beverage Industry Applications:

Food & Beverage Processing: Dairy, breweries, beverage filling lines
Cold Storage & Refrigeration : Chilling storage rooms and transport

Automotive & Aerospace Applications:

Battery Cooling for EVs : Managing temperature in electric vehicle batteries
Aerospace Component Manufacturing : Temperature control in precision machining

Model FM		002-W	003-W	005-W	007-W	010-W	014-W	020-W	024-W
Cooling capacity	kw	1.7	3.3	5.2	7.8	10.8	14.6	20.3	23.6
Compressor abs. Power	kw	0.7	1.3	1.4	1.7	2.5	3.2	4.4	5.4
Power supply	v/oh. / Hz	230/1/50			400/3/50
Protection index		33			54
Refrigerant		R407c
Compressor
Type		Hermetic pistons			scroll
Compressor/ circuit		1/1
Max abs. Power compressor	kw	0.7	1.3	1.5	2.4	3.8	4.4	5.7	6.6
Axial fans
Quantity	N. deg	1	1	1	1	1	1	2	2
Max. abs. Power fan	kw	0.07	0.12	0.12	0.3	0.3	0.4	0.4	0.4
Air flow	m3/h	430	1295	1295	3437	3437	4337	6878	6159
Water cooled version
Condenser water flow	m3/h	N.A					1.5	2.1	2.5
Condenser connections	In	N.A					3/4"	3/4"	3/4"
Pump P30
Max. abs. power	kw	0.4	0.4	0.4	0.9	0.9	1.0	1.3	1.3
Water flow (nom/ max)	m3/h	0.3/ 1.9	0.6/ 1.9	0.9/ 1.9	1.3/ 4.8	1.6/ 4.8	2.5/ 6	3.4/ 9.6	4.9/ 9.6
Head pressure (nom/ max)	m H2O	35/5	35/5	26/5	30/12.8	29/12.8	29/21	29/17.3	28/17.3
Dimension and weight
Width	mm	520	755	755	756	756	756	756	756
Depth	mm	500	535	535	806	806	806	1206	1206
Height	mm	550	801	801	1405	1405	1405	1405	1405
Connection in/out	In	1/2"	3/4"	3/4"	3/4"	3/4"	3/4"	1"	1"
Tank capacity	I	15	15	22.5	65	65	65	100	100
Weight (axial)	kg	40	80	85	160	165	175	220	230
Weight (water cooled)	kg	n/a	n/a	n/a	n/a	n/a	175	220	230
Noise level
Sound pressure (axial)	dB(A)	52	52	52	53	53	50	50	50

At water in/out temperature 20/15 deg C, glycol 0 %, either 25 deg C ambient temperature (air-cooled models) or 25 deg C condenser water inlet temperature with 35 deg C condensing temperature (water-cooled models)

Referred to axial fan version in free feld conditions at a distance of 10 m from until, measured on condenser side, 1 m from ground

Accessories

Water fill kits: non-ferrous pressurized, automatic or ambient manual kits, for water filling in any installation
Remote control kits: base version for remote ON/OFF and general alarm monitoring. Advanced version for complete reunit monitoring.
Wheels (ICEP002- ICEP014): for ease of transport
Water filters: for circuit cleanliness and machinery protection.
Water by-pass: non-ferrous, externally adjustable allowing the correct flow through the system to be set
Control panel cover: from ICEP007,can be supplied already installed.
