Water Cooled Scroll Chiller

Name: Water Cooled Scroll Chiller
Brand: AQUATECH PLUS PVT. LTD.
Price: 800000.0 INR
Availability: InStock

Price 800000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Water Cooled Scroll Chiller Specification

Water Flowing Rate
150 250 LPM (depends on tonnage)

Refrigerating Capacity
2 TR to 100 TR (custom-built as per requirement)

Motor
High Efficiency Induction Motor

Application
Industrial Process Cooling, Plastic Moulding, Pharma, Laser Machines, Beverage Units

Material
Metal

Usage
Industrial

Condition
New

Type
Packaged Water Cooled Scroll Chiller

Dimension (L*W*H)
Depends on Model Millimeter (mm)

Size
Standard

Power Supply
Electric

Product Type
Water Cooled Scroll Chiller

Voltage
220 Volt (v)

Cooling Type
Water Cooled

Color
White

Nozzle Material
Stainless Steel (SS304/SS316)

Cooling Coil Material
Copper Tube with Aluminum Fins / SS Coils

Noise Control
< 70 dB (Low Noise Operation) db

Compressor
Hermetically Sealed Scroll Compressor

Warranty
1 Year

Water Cooled Scroll Chiller Trade Information

Minimum Order Quantity
1 Piece

FOB Port
Mundra

Payment Terms
Cash on Delivery (COD), Cash Advance (CA), Cash in Advance (CID), Cheque, Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T), Letter of Credit (L/C)

Supply Ability
8 Pieces Per Month

Delivery Time
15 Days

Sample Available
No

Packaging Details
Standard and Secure

Main Export Market(s)
Asia, Australia, Central America, Eastern Europe, Western Europe, Middle East, North America, South America, Africa

Main Domestic Market
All India

Certifications
ISO/IEC 17025:2017 , CE, ROHS,ISO 9001:2015 IEC

About Water Cooled Scroll Chiller

Industrial & Manufacturing Applications:

Plastics Processing : Injection molding, blow molding, extrusion
Thermoform Machines Temperature control for plastic sheet forming
Coating Systems : Regulating temperature for uniform coatings
Surface Processing : Electroplating, anodizing, and metal finishing
Welding Engineering : Cooling for welding torches and laser welding
Machine Tools : Spindle cooling, cutting fluid cooling

Energy & Environmental Applications:

Biogas & Natural Gas Treatment : Cooling for gas purification systems
Compressed Air Treatment : Removing moisture in air compression systems
HVAC & Building Cooling : Climate control for commercial buildings

Medical & Pharmaceutical Applications

Chemical & Pharmaceutical Processes : Temperature-sensitive reactions
Medical Imaging Systems : MRI, CT scan cooling
Laser Technology : Cooling for medical and industrial laser systems

Printing & Packaging Applications:

Flexographic Printing Systems : Ink cooling for high-speed printing
Offset Printing Machines: Maintaining ink viscosity and press stability

Advanced Technology & Electronics

Semiconductor & PCB Manufacturing: Cooling electronic components
Data Centers & Server Cooling : Preventing overheating of IT infrastructure

Food & Beverage Industry Applications:

Food & Beverage Processing: Dairy, breweries, beverage filling lines
Cold Storage & Refrigeration : Chilling storage rooms and transport

Automotive & Aerospace Applications:

Battery Cooling for EVs : Managing temperature in electric vehicle batteries
Aerospace Component Manufacturing : Temperature control in precision machining

Model FM		002-W	003-W	005-W	007-W	010-W	014-W	020-W	024-W
Cooling capacity	kw	1.7	3.3	5.2	7.8	10.8	14.6	20.3	23.6
Compressor abs. Power	kw	0.7	1.3	1.4	1.7	2.5	3.2	4.4	5.4
Power supply	v/oh. / Hz	230/1/50			400/3/50
Protection index		33			54
Refrigerant		R407c
Compressor
Type		Hermetic pistons			scroll
Compressor/ circuit		1/1
Max abs. Power compressor	kw	0.7	1.3	1.5	2.4	3.8	4.4	5.7	6.6
Axial fans
Quantity	N. deg	1	1	1	1	1	1	2	2
Max. abs. Power fan	kw	0.07	0.12	0.12	0.3	0.3	0.4	0.4	0.4
Air flow	m3/h	430	1295	1295	3437	3437	4337	6878	6159
Water cooled version
Condenser water flow	m3/h	N.A					1.5	2.1	2.5
Condenser connections	In	N.A					3/4"	3/4"	3/4"
Pump P30
Max. abs. power	kw	0.4	0.4	0.4	0.9	0.9	1.0	1.3	1.3
Water flow (nom/ max)	m3/h	0.3/ 1.9	0.6/ 1.9	0.9/ 1.9	1.3/ 4.8	1.6/ 4.8	2.5/ 6	3.4/ 9.6	4.9/ 9.6
Head pressure (nom/ max)	m H2O	35/5	35/5	26/5	30/12.8	29/12.8	29/21	29/17.3	28/17.3
Dimension and weight
Width	mm	520	755	755	756	756	756	756	756
Depth	mm	500	535	535	806	806	806	1206	1206
Height	mm	550	801	801	1405	1405	1405	1405	1405
Connection in/out	In	1/2"	3/4"	3/4"	3/4"	3/4"	3/4"	1"	1"
Tank capacity	I	15	15	22.5	65	65	65	100	100
Weight (axial)	kg	40	80	85	160	165	175	220	230
Weight (water cooled)	kg	n/a	n/a	n/a	n/a	n/a	175	220	230
Noise level
Sound pressure (axial)	dB(A)	52	52	52	53	53	50	50	50

At water in/out temperature 20/15 deg C, glycol 0 %, either 25 deg C ambient temperature (air-cooled models) or 25 deg C condenser water inlet temperature with 35 deg C condensing temperature (water-cooled models)

Referred to axial fan version in free feld conditions at a distance of 10 m from until, measured on condenser side, 1 m from ground

Accessories

Water fill kits: non-ferrous pressurized, automatic or ambient manual kits, for water filling in any installation
Remote control kits: base version for remote ON/OFF and general alarm monitoring. Advanced version for complete reunit monitoring.
Wheels (ICEP002- ICEP014): for ease of transport
Water filters: for circuit cleanliness and machinery protection.
Water by-pass: non-ferrous, externally adjustable allowing the correct flow through the system to be set
Control panel cover: from ICEP007,can be supplied already installed.

Superior Industrial Cooling Solution

This water cooled scroll chiller is engineered for robust industrial settings including plastic moulding, pharmaceutical production, laser cooling, and beverage units. Its premium materials and advanced components ensure optimal thermal management and energy efficiency, offering critical support to seamlessly maintain low process temperatures across various industrial operations.

Durable and Customizable Construction

Utilizing corrosion-resistant stainless steel for nozzles and copper/aluminum or stainless steel tubes for the cooling coil, this chiller guarantees extended service life and minimal maintenance. Each unit is available in standard and custom-built sizes, with refrigeration capacity scaling from 2 TR up to 100 TR as per client requirements.

FAQs of Water Cooled Scroll Chiller:

Q: How does a packaged water cooled scroll chiller operate in industrial environments?

A: A packaged water cooled scroll chiller circulates cool water through process equipment, absorbing excess heat. The water then returns to the chiller, where a scroll compressor and high-efficiency induction motor drive the cooling cycle. This process keeps temperatures controlled for industrial applications like molding or pharmaceutical production.

Q: What are the main benefits of using a water cooled scroll chiller for industrial process cooling?

A: The key benefits include high energy efficiency, lower operational noise (below 70 dB), and superior thermal regulation. Built with robust materials such as stainless steel and copper, these chillers provide reliable and hygienic cooling with minimal downtime, supporting consistent process operation.

Q: When should I consider choosing a scroll chiller with a custom refrigeration capacity?

A: You should opt for a custom-built chiller when your cooling demand doesnt align with standard models. These chillers can be tailored from 2 TR to 100 TR, ensuring precise cooling capacity for unique process requirements or large-scale industrial setups.

Q: Where is the ideal installation location for a packaged water cooled scroll chiller?

A: These chillers are best installed in sheltered utility areas that provide access to the cooling water supply and drainage. They suit factories, manufacturing plants, or industrial facilities where process cooling is essential, and good ventilation helps ensure optimal performance.

Q: What maintenance steps are needed for this water cooled scroll chiller?

A: Routine maintenance consists of inspecting water quality to prevent scaling, checking the stainless steel nozzles and copper/aluminum coils for corrosion, and servicing the hermetically sealed scroll compressor as per the manufacturers guidelines. Regular maintenance ensures sustained efficiency and longevity.

Q: How does the use of SS304/SS316 nozzles and copper tube cooling coils benefit performance?

A: Stainless steel and copper components enhance both hygiene and durability. Stainless steel nozzles resist corrosion, making them ideal for various water types. Copper tube coils with aluminum fins or SS coils provide efficient heat transfer, leading to more effective and long-lasting process cooling.
